Integrated Alkaline water Electrolyzer (AWE) Hydrogen Production System
JSDJ-YJU Series
YJU series hydrogen production system has an integrated structure;
The electrolyzer and the separation and purification system are integrated in one frame, with compact structure and small footprint;
Suitable for scientific research in universities and power plant generator set cooling.
H₂ Output
5-20Nm³/h
H₂ Purity
99.999%
Output Pressure
1.5-3.2Mpa
Operating Temperature
90±5 ℃
Dew Point
≤-60 ℃
O₂ Content
≤ 1ppm
Containerized Alkaline water Electrolyzer (AWE) Hydrogen Production System
JSDJ-YJC Series
YJC series hydrogen production system has a containerized structure;
The electrolyzer and the separation, purification and auxiliary systems are all integrated in the container, which is simple and beautiful;
The system is easy to be transported and installed.
Suitable for distributed hydrogen production and refueling station.
H₂ Output
5-100Nm³/h
H₂ Purity
99.999%
Output Pressure
0.8-3.2Mpa
Operating Temperature
90±5 ℃
Dew Point
≤-60 ℃
O₂ Content
≤ 1ppm
Split-mounted Alkaline water Electrolyzer (AWE) Hydrogen Production System
JSDJ-YJ Series
YJ series hydrogen production system has a split-mounted structure;
The separation and purification system adopts the frame structure and the equipment layout is reasonable, which is easy to install, operate and maintain;
Full automatic control with beautiful control interface for simple operation, safe and reliable.
Suitable for green hydrogen production, energy and chemical industries.
H₂ Output
5-2000Nm³/h
H₂ Purity
99.999%
DC Power Consumption
≤4. 3kwh/nm³
Load Range
20%-120%
Dew Point
≤-72 ℃
O₂ Content
≤ 1ppm
Four-to-one Alkaline water Electrolyzer (AWE) Hydrogen Production System
JSDJ-YJM Series
YJM series hydrogen production system has a four-to-one structure (four electrolyzers share one separation system);
Reduce the number of separation and purification systems as well as investment costs;
Advanced control algorithm is used for the system to run safely and stably;
Suitable for large-scale green hydrogen production plants.
H₂ Output
4000Nm³/h
H₂ Purity
99.999%
DC Power Consumption
≤4. 3kwh/nm³
Load Range
20%-120%
Dew Point
≤-72 ℃
O₂ Content
≤ 1ppm
The company has the world's top hydrogen ammonia field experts and partners, with technology to accelerate the marketization of green hydrogen.
